MMC.F140.c – developed for high-end-E-MTBs

When developing this new platform, Messingschlager was concerned with designing a carbon frame based on the most modern geometric approaches for all-mountain/trail applications. We followed a clear goal: to develop a modern carbon design at an attractive price. What is interesting about our MMC. F140.c: as well as the main frame, the rear end and shock absorber rocker also made of carbon ensuring a low overall weight.

With this frame as a basis, complete bicycles weighing less than 22 kg can be built. In addition to its low weight, the use of mixed wheel sizes with 29“, 27.5“ or Mullet system are possible. For the motor, we opted for the high performance and power of the Brose Drive S Mag with a maximum torque of up to 90 Nm. The new Brose battery with 630 Wh is fully integrated in the down tube. For the display we recommend minimalist solutions with the Brose Display Remote or Allround.

Categorization:

The frame, shock absorber and rear end are made of high-quality carbon fibers. This guarantees a low weight with optimal rigidity.

When it comes to the built-in components of the motor system, we rely on the entire Brose product range.

Design and formal language are modern and independent, but do not have a polarizing eff ect on the viewer.

Key Facts

To ensure the greatest variability our E-All Mountain was designed so that both 27.5“ and 29“ wheels can be mounted.

The heart of our full suspension is formed by the Brose Drive S Mag, which has achieved a maximum torque of 90 Nm with a weight of only 2.9 kg.

When coordinating the suspension travel of up to 140 mm, our developers paid attention to a progressive characteristic curve for perfect performance.

This powerful unit is supplied with electricity by a fully integrated battery, which has a capacity of 630 Wh and guarantees the best range.

System

Brose Remote Display | Brose Drive S Mag | Brose Akku with 630 Wh

In our newly developed e-all-mountain with a carbon frame, we are one of the first providers to install the complete system from Brose.

This complete package includes the Brose Drive S Mag motor, the newly developed Brose battery with 630 Wh and the extremely compact Remote Display, also from Brose.

This system underlines the sporty approach of our frame platform and enables the construction of strong and smooth performance E-MTBs.

Geometry

Fully

FULLY	S/M	M/L	L/XL
Seat tube length	400 mm	420 mm	480 mm
Top tube length horizontal	600 mm	632 mm	664 mm
Steerer tube	118 mm	140 mm	162 mm
Chain stay	465 mm	465 mm	465 mm
Steerer tube angle	66°	66°	66°
Seat tube angle	74.86°	74.74°	74.62°
Wheelbase	1219 mm	1252 mm	1286 mm
Reach	434 mm	460 mm	485 mm
Stack	610 mm	630 mm	650 mm
Head set (S.H.I.S.)	ZS44/28.6 ZS56/40	ZS44/28.6 ZS56/40	ZS44/28.6 ZS56/40
Fork installation height	551 mm	551 mm	551 mm
Seat post Ø	31.6 mm	31.6 mm	31.6 mm
