MMC.F140.c – developed for high-end-E-MTBs

When developing this new platform, Messingschlager was concerned with designing a carbon frame based on the most modern geometric approaches for all-mountain/trail applications. We followed a clear goal: to develop a modern carbon design at an attractive price. What is interesting about our MMC. F140.c: as well as the main frame, the rear end and shock absorber rocker also made of carbon ensuring a low overall weight.

With this frame as a basis, complete bicycles weighing less than 22 kg can be built. In addition to its low weight, the use of mixed wheel sizes with 29“, 27.5“ or Mullet system are possible. For the motor, we opted for the high performance and power of the Brose Drive S Mag with a maximum torque of up to 90 Nm. The new Brose battery with 630 Wh is fully integrated in the down tube. For the display we recommend minimalist solutions with the Brose Display Remote or Allround.

Categorization:

Bike-Kategorie 4 Icon
Bike Detail 1

The frame, shock absorber and rear end are made of high-quality carbon fibers. This guarantees a low weight with optimal rigidity.

Bike Detail 2

When it comes to the built-in components of the motor system, we rely on the entire Brose product range.

Bike Detail 3

Design and formal language are modern and independent, but do not have a polarizing effect on the viewer.

Key Facts

Key Features 1

To ensure the greatest variability our E-All Mountain was designed so that both 27.5“ and 29“ wheels can be mounted.

Key Features 2 Key Features 2

The heart of our full suspension is formed by the Brose Drive S Mag, which has achieved a maximum torque of 90 Nm with a weight of only 2.9 kg.

Key Features 3 Key Features 3

When coordinating the suspension travel of up to 140 mm, our developers paid attention to a progressive characteristic curve for perfect performance.

Key Features 4 Key Features 4

This powerful unit is supplied with electricity by a fully integrated battery, which has a capacity of 630 Wh and guarantees the best range.

System

Systemkomponenten

Brose Remote Display | Brose Drive S Mag | Brose battery with 630 Wh

In our newly developed e-all-mountain with a carbon frame, we are one of the first providers to install the complete system from Brose.

This complete package includes the Brose Drive S Mag motor, the newly developed Brose battery with 630 Wh and the extremely compact Remote Display, also from Brose.

This system underlines the sporty approach of our frame platform and enables the construction of strong and smooth performance E-MTBs.

Geometry

Geometrie

Fully

FULLY S/M M/L L/XL
Seat tube length 400 mm 420 mm 480 mm
Top tube length horizontal 600 mm 632 mm 664 mm
Steerer tube 118 mm 140 mm 162 mm
Chain stay 465 mm 465 mm 465 mm
Steerer tube angle 66° 66° 66°
Seat tube angle 74.86° 74.74° 74.62°
Wheelbase 1219 mm 1252 mm 1286 mm
Reach 434 mm 460 mm 485 mm
Stack 610 mm 630 mm 650 mm
Head set (S.H.I.S.) ZS44/28.6
ZS56/40		 ZS44/28.6
ZS56/40		 ZS44/28.6
ZS56/40
Fork installation height 551 mm 551 mm 551 mm
Seat post Ø 31.6 mm 31.6 mm 31.6 mm
